Explosion proof signs Exd Ⅱ CT6/DIP A20 TA, T6

Explosion proof certificate number CNEx17.1203X

Patent number ZL201620739779.3

Voltage 12VDC/POE

Working current ≤ 1.25A

Power consumption ≤ 15W

Electrical connection 2-core cable for power input coaxial cable for video signal output RJ45

Mechanical indicators

Material: stainless steel 304 or 316L

Protection level IP68

Window transparent component thickness 10mm

Window diameter 80mm

Weight/Transportation Weight 8Kg/10Kg

Number of outlet holes 2

Thread size of outlet hole G-3/4 "

Installation method: electric pan tilt, semi fixed pan tilt, fixed bracket

Camera (Weishi 3 million pixels)

Sensor type 1/3 "Progressive Scan CMOS

Minimum illumination 0.07 Lux @ (F1.2, AGC ON), 0 Lux with IR

0.1 Lux @ (F1.4, AGC ON), 0 Lux with IR

Shutter 1/3 second to 1/100000 second

Lens 4mm, horizontal field of view angle: 60.5 ° (6mm, 8mm, 12mm optional)

Day night conversion mode ICR infrared filter type

Wide dynamic range digital wide dynamic range

Digital noise reduction 3D digital noise reduction

Compression standard

Video compression standards H.265/H.264/MJPEG

H. 265 encoding type Main Profile

H. 264 encoding type BaseLine Profile/Main Profile

Compressed output bit rate of 32 Kbps~8Mbps


Maximum image size 2048 x 1536

Frame rate 50Hz: 25fps (2048 x 15361920 x 10801280 x 720)

Image setting corridor mode, saturation, brightness, contrast, and sharpness can be adjusted through the client or browser

Backlight compensation support with selectable regions

Region of interest ROI supports setting one fixed region for each of the three bitstreams

Network functions

Interface protocols ONVIF, PSIA, CGI, ISAPI, GB28181

Intelligent alarm for mobile detection, dynamic analysis, obstruction alarm, network cable disconnection, IP address conflict, memory full, memory error

Intelligent alarm boundary detection, area intrusion detection, scene change detection, face detection, virtual focus detection, item leaving detection, item picking detection, illegal parking detection, personnel gathering detection, retrograde detection, hovering detection, rapid movement detection, entering area detection, leaving area detection

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour

Universal functions include three streams, heartbeat, mirroring, password protection, video masking, watermark technology, anonymous access, and IP address filtering

Interface

Communication interface: 1 RJ45 10M/100M adaptive Ethernet port

General specifications

Power supply DC12V ± 25%/PoE (802.3af)

Power consumption 10.5W MAX

Infrared irradiation distance of 30 meters/50 meters/80 meters
