Explosion proof network hemisphere

Changzhou DERKE Mechanical Equipment Co., Ltd. is a high-tech enterprise that integrates explosion-proof cameras, high-temperature industrial TV design, production, sales, after-sales service, and industrial TV systems. The company's main products include explosion-proof cameras, high-temperature industrial televisions, body scanners, industrial monitoring system engineering, etc.

Contact US

Detail

Exd Ⅱ CT6 Gb/Ex tD A20 T80 ℃

Explosion proof certificate number: CNEx17.0053X


Voltage 12VDC/POE


Working current ≤ 0.8A


Power consumption ≤ 10W


Electrical connection 2-core cable for power input coaxial cable for video signal output RJ45


Mechanical indicators


Material: stainless steel 304 or 316L


Protection level IP68


Window transparent component thickness 10mm


Weight/Transportation Weight 3Kg/5Kg


Number of outlet holes 1


Thread size of outlet hole G-3/4 "


Installation method: fixed bracket




Camera (Weishi 3 million pixels)


Sensor type 1/3 "Progressive Scan CMOS


Minimum illumination 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR


0.1 Lux @ (F1.4, AGC ON), 0 Lux with IR


Shutter 1/3 second to 1/100000 second


Lens 4mm, horizontal field of view angle: 60.5 ° (6mm, 8mm, 12mm optional)


Day night conversion mode ICR infrared filter type


Wide dynamic range digital wide dynamic range


Digital noise reduction 3D digital noise reduction


Compression standard


Video compression standards H.265/H.264/MJPEG


H. 265 encoding type Main Profile


H. 264 encoding type BaseLine Profile/Main Profile


Compressed output bit rate of 32 Kbps~8Mbps




Maximum image size 2048 x 1536


Frame rate 50Hz: 25fps (2048 x 15361920 x 10801280 x 720)


Image setting corridor mode, saturation, brightness, contrast, and sharpness can be adjusted through the client or browser


Backlight compensation support with selectable regions


Region of interest ROI supports setting one fixed region for each of the three bitstreams




Network functions


Interface protocols ONVIF, PSIA, CGI, ISAPI, GB28181


Intelligent alarm for mobile detection, dynamic analysis, obstruction alarm, network cable disconnection, IP address conflict, memory full, memory error


Intelligent alarm boundary detection, area intrusion detection, scene change detection, face detection, virtual focus detection, item leaving detection, item picking detection, illegal parking detection, personnel gathering detection, retrograde detection, hovering detection, rapid movement detection, entering area detection, leaving area detection


Supports protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X,


QoS, IPv6, Bonjour


Universal functions include three streams, heartbeat, mirroring, password protection, video masking, watermark technology, anonymous access, and IP address filtering


Interface


Communication interface: 1 RJ45 10M/100M adaptive Ethernet port


Infrared irradiation distance of 20 meters/30 meters

5
