Exd Ⅱ CT6 Gb/Ex tD A20 T80 ℃

Explosion proof certificate number: CNEx17.0052X

Intelligent fire point detection function with multi-level fire point detection, efficient detection, reducing false alarms, doubling visible light linkage, and viewing surrounding conditions

Perceived intelligent rules support area intrusion, boundary crossing, entry/exit area detection

Excellent thermal imaging effect with a resolution of 384 x 288

Maximum temperature cross positioning, supporting 1 line temperature measurement, 10 frame temperature measurements, and 10 point temperature measurements, with 100 associated temperature measurement preset positions

Temperature measurement range: -40 ℃~550 ℃, temperature measurement accuracy: ± 2 degrees (or ± 2% of the range)

Temperature abnormal alarm

Precision motor drive, sensitive response, smooth operation, accuracy deviation less than 0.1 degrees, no image shake at any speed

• Supports power-off state memory function, automatically returning to the pan tilt and lens state before power-off after power-off

Support lightning protection, surge prevention, and surge prevention

Mechanical indicators

Material: stainless steel 316L

Protection level: IP68

Dimensions of the inner chamber of the protective cover for use: 220 (L) x 80 (W) x 70 (H) mm

Horizontal rotation: 360 °

Vertical rotation:+90 °~-90 °

Horizontal rotation speed: 0.1-40 °/S

Vertical rotation speed: 0.1-40 °/S

Unit weight: 32Kg

Transportation weight: 35Kg

Installation method: fixed bracket, base, column

Electrical indicators

Input voltage: 220VAC DC24V

Input voltage range: ± 10%

Working current: ＜ 500mA (220VAC) Power consumption: approximately 100W

Communication method: RS-485

Communication speed: adaptive

Communication protocol: PELCO-D/P ONVIF2.0

Infrared distance: 50, 80, 100 meters

Number of preset positions: 256

Pre positioning accuracy: ≤ 0.1 °

Electrical connection: 3-core cable connects to power supply, 2-core shielded cable connects to control signal, coaxial cable outputs video signal or RJ45

Infrared thermal imager

Detector type: non cooled focal plane micro thermal type

Pixel 384 x 288

Pixel spacing 17 μ  M

Working wavelength 7.5-14 μ  M

Thermal sensitivity ＜ 0.04 ℃ @ 30 ℃

Lens parameters

Lens types 19mm, 25mm, 35mm, 50mm, 75mm heat dissipation differential lenses

15mm, 25mm, 35mm, 50mm, 75mm electric lenses

Focal length 25mm/F=1

Field of view 24 ° x 18 °

Frame rate 50Hz

Focusing on electric, supporting autofocus

Clear imaging range of 0.3m~∞

Temperature measurement performance

Temperature measurement range -20 ℃~+150 ℃ (standard),+180 ℃~+600 ℃ (optional)

Temperature measurement accuracy of ± 2 ℃ or ± 2%, whichever is higher

Display enhancement automatic stretching, DDE digital image detail enhancement

The emissivity black background temperature calibration is automatically calibrated based on the input emissivity and background temperature,

Emissivity adjustable from 0.01 to 1

Filter or window transmittance correction automatically adjusts based on input transmittance

Atmospheric transmittance correction automatically calculates atmospheric transmittance and corrects temperature based on meteorological parameters

Real time display of high temperature point position and temperature through tracking the highest temperature

Color palette gray, colored, iron red

Electronic zoom 2x, 4x

Camera 2 2 million

20x 2.1 million 1/2.8 "CMOS ICR day and night network high-definition all-in-one machine

Sensor type: 1/2.8 "Progressive Scan CMOS

Signal system: PAL/NTSC

Day night conversion mode: ICR infrared filter type

Signal to noise ratio: greater than 52dB

Electronic shutter: 1/1 second~1/30000 second

Resolution:

50Hz: 25fps (1920x1080) 60Hz: 30fps (1920x1080)

50Hz: 25fps (1280x720) 60Hz: 30fps (1280x720)

Minimum illumination:

Color: 0.05Lux @ (F1.6, AGC ON)

Black and white: 0.01Lux @ (F1.6, AGC ON)

White balance: automatic 1/automatic 2/indoor/outdoor/manual/sodium lamp/fluorescent lamp

3D noise reduction: supported

Focal length: 4.7-94mm, 20x optical

Aperture: F1.6-F3.5

Horizontal viewing angle: 61.4-2.9 degrees (wide angle - far view)

Close up range: 10-1500mm (wide-angle telescope)

Multiplying speed: approximately 2.7 seconds (optical, wide-angle telescope)

Exposure mode: automatic exposure/aperture priority/shutter priority/manual exposure

Focus mode: automatic focus/one-time focus/manual focus

Wide dynamic: off/on, 4-level adjustable

Video compression standard: H.264/MJPEG

Compressed output bit rate: 32 Kbps~16Mbps

Image settings: saturation, brightness, and contrast can be adjusted through the client or IE browser

Storage function: supports micro SD

Intelligent alarm: movement detection, obstruction alarm, memory full, memory error

Supported protocols: TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, UPnP, SNMP, FTP, 802.1x, QoS, HTTPS, IPv6 (SIP, SRTP, optional)

Universal features: dual stream, heartbeat, password protection

Communication interface: 1 RJ45 10M/100M adaptive Ethernet port, 1 RS-485 interface

Interface protocols: ONVIF, PSIA, CGI
